Solar Powered Wireless Temperature Sensor

Solar Powered Wireless Temperature Sensor

Integrated with telematics

The innovative Solar Powered Wireless Temperature Sensor integrated with telematics eliminates labor intensive and time consuming manual battery charging , increasing productivity and efficiency while reducing maintenance costs.

features

Previous
Next

IoT Applications

An all-in-one scalable solution for the cold chain

How it works

The RFLink solution is an Active RFID gps tracking system that is comprised of small, battery powered RFTags packaged in an IP67 waterproof enclosure.

The RFTags are placed on trailers, containers or any asset to be monitored and a Piccolo Plus with an RFLink module is installed in any truck.

The RFTags communicate via RF at 2.4GHz to the Piccolo Plus Gateway at a radius of up to 250 feet (70m).

In addition to sending GPS position, driver behavior, and via-the-air engine diagnostics, the Piccolo Plus communicates wirelessly to the RFTags placed on every asset and receives unique tag ID, signal strength, and temperature data.
Each RFTag automatically detects and connects to any number of Piccolo Plus units defined within a system.

The data received from the RF Tags is processed by the Piccolo Plus and routed to the Fleet.Net platform with the date, time and GPS location where the link was established
(which is the pickup and drop off location).



The RFTag has a powerful 32bit CPU with a 2.4 GHz IEEE802.15.4 transceiver and is packaged with a small 200mAh or 500mAh rechargeable lithium battery capable of powering the RFTag for up to 24 months.

For cold chain monitoring, an external digital temperature sensor can be added for wireless temperature monitoring.

Product Features

External digital temp sensor: High accuracy of +/- 0.9°F (0.5°C).

Up to 24 months of continuous operation with an integrated 200mAh or 500mAh rechargeable lithium battery.

Extends battery life to 5 years

For certain applications in which the 210ft (70m) communication range is too powerful, the RFTag communication range can be shortened to 3ft, 6ft, 15ft, 30ft (1m,2m,5m or 10m) as needed.

Designed for harsh working environments, each RFTag is packaged in a robust IP67 rated enclosure.

Can also function as a wireless remote I/O for detecting door open/closed events.

Technical Specifications

Cellular Frequency Bands- 2.4Ghz IEEE 802.15.9

The RFTags communicate via RF at 2.4GHz to the Piccolo Plus Gateway at a radius of up to 250 feet (70m).

  • Dimensions
    2.63″ x 1.49″ x 0.67″ ( 67mm x 38mm x17mm)
  • IP67 waterproof enclosure
  • Operating Temperature: 180mAh battery: -22º to 176º F (-30º to 80º C) / CR 2450 3v battery: 14º to 176º F (-10º to 80º C)
  • Storage Temperature: -40º to 185º F (-40º to 85º C)
    Humidity: 0 to 99% 110F (40C), non-condensing
  • Battery – integrated 200mAh or 500mAh rechargeable lithium battery
  • 3M two sided tape
  • Magnets for mounting on metal surfaces
  • Bolt in place with one screw

Get A Quote

Fill out the form below and a member of our sales team will get back to you

Frequently Asked Questions

The best wireless temperature monitoring device is one that fits your needs. the Piccolo TMX enables real-time location and temperature monitoring with a battery life of up to 5000 messages.

The wireless device can transmit up to 5,000 messages. For further battery life conservation, the unit can be programmed to accumulate readings and send at a defined time frame for example every 60 minutes.

The device is wireless. Simply place in desired area.

Yes, The device enables real-time location and temperature tracking of valuable perishable goods inside pallets, cargo, parcels ,trailers or shipping containers. You can also set it so it sends data at a given time. This is customizable to your needs.

Cost depends on volume and added features. Talk to us today to get a price quote.

Yes, the wireless temperature monitoring device is packages in an IP67 waterproof enclosure.

The wireless temperature monitoring device sends immediate alerts on temperature changes to the driver as well as the dispatcher so you can quickly respond and avoid cargo spoilage.

The wireless temperature monitoring device is designed to monitor the temperature of food packages or boxes or pharmaceutical goods inside Pallets, Cargo and Parcels.

The wireless temperature monitoring device is designed to monitor goods such as pharmaceutical shipments. It is wireless so it is designed to be placed inside the package of the shipment.

The device supports up to 6 wired digital temperature sensors, with an accuracy of +/- 0.5˚C, +/- 0.9˚F.

The major benefits of a wireless temperature monitoring solution is that you simply place it anywhere you need and it starts tracking temperature and location.

Place in temperature sensitive packages, boxes, pallets, shipments and more to gain visibility and avoid spoilage.
